X-Ray Fluorescence (XRF) Analyzers are powerful, non-destructive instruments used to determine the elemental composition of a wide range of materials with exceptional accuracy and speed. By using high-energy X-rays to excite atoms within a sample, XRF technology provides precise identification and quantification of elements from sodium (Na) to uranium (U), making it one of the most versatile analytical solutions available.
XRF analyzers are widely used across industries such as metals and alloys, mining, cement, petrochemicals, electronics, environmental testing, and quality control laboratories. With minimal sample preparation, fast analysis times, and the ability to test solids, liquids, powders, and coatings, XRF systems deliver reliable results that support production monitoring, material verification, and compliance with international standards.
.png)
X-ray fluorescence analyzer provides stable, most accurate and most economic methods for the determination. It is an ideal analyzer to control the quality of products.
It can be used for wide range of elements, from Na (11)- U (92）
The Silicon Drift Detector with multi-channel analyzer detects the X-ray fluorescence radiation and accumulates counts to form an intensity versus energy spectrum of the sample.
Features
1.High accuracy and affordable.
2. Complete analysis within a few seconds.
3. Optimized to customer requirements and optimal advisory services.
4. Open working curve, tailor-made for the user with the best detection and control program of hazardous substances.
5. Easily upgrade for future test samples types expansion.
6. Automatic quantitative analysis report is concise and accurate
7. It has the function of automatically detecting the working state of the instrument.
8. Humanized design, configuring as a bench top or floor model with storage possibilities for consumables and spares.
.png)
It can be used for wide range of elements, from Na (11)-U(92）.
The Silicon Drift Detector with multi-channel analyzer detects the X-ray fluorescence radiation and accumulates counts to form an intensity versus energy spectrum of the sample.
Features
1.Highly efficient and extremely thin window X-ray tube which achieves international advanced level.
2.Silicon Drift Detector (SDD), great energy linearity,excellent energy resolution and spectrum, high peak/base rate
3.Low energy X-ray excitation to elements, great excitation to Si, P and other light elements
4.Intelligent vacuuming system eliminates air influences, which greatly improves testing range
5.Automatic spectrum-stabilizing device ensures stability of the instrument
6.High Signal-to-Noise electronic circuit unit
7.Automatic switch of collimators and filters instead of manual operation
8.Analysis spectrum technology ensures great repeatability
9.Multi-parameter linear regression method restrains absorptions between different elements
10.Built-in HD camera
11.LCD screen directly displays testing results (tube voltage, tube current, and vacuum degree)
